Specification	1814838

Color	Black
Contact Mating Finish	Tin
Current - IEC	6 A
Current - UL	5 A
Header Orientation	Right Angle
Header Orientation Angle	90 °
Mounting Type	Through Hole
Number of Levels	1
Number of Positions	8
Pitch	0.098 in
Positions Per Level	8
Termination Style	Solder
Type	Shrouded (4 Side), Male Pins, Header
Voltage - IEC	50 V
Voltage - UL	150 V
