B72.915LHB.00110
ObsoleteApacer Memory America
M242 NVME 3X2 BICS5 960GB WT
B72.915LHB.00110
ObsoleteApacer Memory America
M242 NVME 3X2 BICS5 960GB WT
Description
General part information
B72.915LHB.00110
Solid State Drive (SSD) FLASH - NAND (TLC) 960GB NVMe M.2 Module 3.3V
Technical Specifications
Parameters and characteristics for this part
| Specification | B72.915LHB.00110 |
|---|---|
| Current - Max | 615 mA |
| Form Factor | M.2 Module |
| Memory Size | 960 GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Size / Dimension Height | 3.88 mm |
| Size / Dimension Length | 42 mm |
| Size / Dimension Width | 22 mm |
| Speed - Read | 1.6 GB/s |
| Speed - Write | 1.355 GB/s |
| Type | NVMe |
| Voltage - Supply | 3.3 V |
