A1210E-B
ActiveSensata-Crydom
SSR RELAY SPST-NC 10A 24-140V
Deep-Dive with AI
Search across all available documentation for this part.
A1210E-B
ActiveSensata-Crydom
SSR RELAY SPST-NC 10A 24-140V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | A1210E-B |
|---|---|
| Approval Agency | CSA, CE, UL, TUV |
| Circuit | SPST-NC (1 Form B) |
| Load Current | 10 A |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -40 °C |
| Output Type | AC, Zero Cross |
| Package / Case | Hockey Puck |
| Termination Style | Screw Terminal |
| Voltage - Input [Max] | 36 VAC |
| Voltage - Input [Min] | 18 VAC/DC |
| Voltage - Load [Max] | 140 V |
| Voltage - Load [Min] | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 20 | $ 65.78 | |
Description
General part information
A1210E-B
Solid State SPST-NC (1 Form B) Hockey Puck
