31049105
ActiveMETZ CONNECT USA Inc.
SCREW TYPE TERMINAL BLOCK, PLUG,
Deep-Dive with AI
Search across all available documentation for this part.
31049105
ActiveMETZ CONNECT USA Inc.
SCREW TYPE TERMINAL BLOCK, PLUG,
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 31049105 |
|---|---|
| Color | Black |
| Contact Material | Copper Beryllium |
| Contact Mating Finish | Silver |
| Insulation Height | 0.5 in |
| Insulation Height | 12.7 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Positions Per Level | 5 |
| Screw Size | M3 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw | 0.79 Nm |
| Torque - Screw | 7 Lb-In |
| Type | Plug, Female Sockets |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 22 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Gauge or Range - mm² [Max] | 2.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.33 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 250 | $ 2.99 | |
Description
General part information
31049105
5 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 180° Free Hanging (In-Line)
