Description
General part information
LEFB4B003480B
CONTACTOR,LTG,EH,N4X,20A,3NO,480
Technical Specifications
Parameters and characteristics for this part
| Specification | LEFB4B003480B |
|---|---|
| Coil Power | 31.7 VA |
| Coil Voltage | 480 VAC |
| Contact Form | A, PST-NO, Form, 3 |
| Contact Rating (Current) | 20 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 408 VAC |
| Operating Temperature (Max) | 40 °C |
| Operating Temperature (Min) | 0 °C |
| Pin Count | 3 pins |
| Switching Voltage AC (Max) | 600 VAC |
| Termination Style | Screw Terminal |
