Part	Termination	Contact Material	Contact Length - Mating	Features	Connector Type	Material Flammability Rating	Contact Shape	Contact Finish - Post	Contact Length - Post	Number of Rows	Insulation Color	Number of Positions	Mounting Type	Contact Type	Insulation Height	Insulation Material	Operating Temperature (Max)	Operating Temperature (Min)	Contact Finish - Mating	Style	Number of Positions Loaded	Fastening Type	Pitch - Mating	Shrouding	For Use With/Related Products	Accessory Type	Mated Stacking Height	Note	Pitch	Color	Contact Termination	Pin or Socket	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Contact Finish
Hirose Electric Co Ltd DF7-3P-3.96DS(25)	Solder	Copper Alloy	0.276 in	Board Guide	Header	UL94 V-0	Square	Tin	0.138 in	1	Beige	3	Right Angle Through Hole	Male Pin	0.303 in	Glass Filled Nylon Polyamide (PA)	85 °C	-35 °C	Tin	Board Cable/Wire	All	Latch Holder	0.156 in	Shrouded - 4 Wall
Hirose Electric Co Ltd DF7-3P-3.96DS(01)	Solder	Copper Alloy	0.276 in	Board Guide	Header	UL94 V-0	Square		0.138 in	1	Beige	3	Right Angle Through Hole	Male Pin	0.303 in	Glass Filled Nylon Polyamide (PA)	85 °C	-35 °C	Gold	Board Cable/Wire	All	Latch Holder	0.156 in	Shrouded - 4 Wall
Hirose Electric Co Ltd DF7-1RS/P-3.96												1													DF7 Series	Retainer Clip
Hirose Electric Co Ltd DF7-9P-3.96DS(26)	Solder	Copper Alloy	0.276 in	Board Guide	Header	UL94 V-0	Square		0.138 in	1	Beige	9	Right Angle Through Hole	Male Pin	0.303 in	Glass Filled Nylon Polyamide (PA)	85 °C	-35 °C	Gold	Board Cable/Wire	All	Latch Holder	0.156 in	Shrouded - 4 Wall
Hirose Electric Co Ltd DF7-7P-3.96DSA(26)	Solder	Copper Alloy	0.276 in	Board Guide	Header	UL94 V-0	Square		0.138 in	1	Beige	7	Through Hole	Male Pin	0.508 in	Glass Filled Nylon Polyamide (PA)	85 °C	-35 °C	Gold	Board Cable/Wire	All	Latch Holder	0.156 in	Shrouded - 4 Wall			21.5 mm
Hirose Electric Co Ltd DF7-7P-3.96DS	Solder	Copper Alloy	0.276 in	Board Guide	Header	UL94 V-0	Square	Tin	0.138 in	1	Beige	7	Right Angle Through Hole	Male Pin	0.303 in	Glass Filled Nylon Polyamide (PA)	85 °C	-35 °C	Tin	Board Cable/Wire	All	Latch Holder	0.156 in	Shrouded - 4 Wall
Hirose Electric Co Ltd DF7-8P-3.96DS(25)	Solder	Copper Alloy	0.276 in	Board Guide	Header	UL94 V-0	Square	Tin	0.138 in	1	Beige	8	Right Angle Through Hole	Male Pin	0.303 in	Glass Filled Nylon Polyamide (PA)	85 °C	-35 °C	Tin	Board Cable/Wire	All	Latch Holder	0.156 in	Shrouded - 4 Wall
Hirose Electric Co Ltd DF7-3RS/P-3.96												3													DF7 Series	Retainer Clip
Hirose Electric Co Ltd DF7-3S-3.96C					Receptacle					1		3	Free Hanging (In-Line)	Female Socket								Latch Lock						Contacts Not Included	0.156 in	White	Crimp
Hirose Electric Co Ltd DF7-2022SC																															Crimp	Socket	19.5 AWG	22 AWG	Tin
