Specification	MC9328MX1CVM15R2

Additional Interfaces	I2C, SPI, MMC, UART, I2S, SD, SSI
Bus Width	32 Bit
Core Processor	ARM920T
Display & Interface Controllers	LCD, Touch Panel
Graphics Acceleration	No
Mounting Type	Surface Mount
Number of Cores	1 Core
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	256-MAPBGA
RAM Controllers	SDRAM
Speed	150 MHz
USB	USB 1.x (1)
Voltage - I/O (Option 1)	1.8 V
Voltage - I/O (Option 2)	3 V

MC932 Series

Part	Speed	Operating Temperature (Min)	Operating Temperature (Max)	Display & Interface Controllers	Package / Case	Additional Interfaces	Mounting Type	Bus Width	Number of Cores	Package Name	Package Length	Package Width	Core Processor	Voltage - I/O (Option 2)	Voltage - I/O (Option 1)	Graphics Acceleration	USB	RAM Controllers
NXP USA Inc. MC9328MXLVP20R2	200 MHz	0 °C	70 °C	LCD	225-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	225-MAPBGA	13 mm	13 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MXLCVP15	150 MHz	-40 °C	85 °C	LCD	225-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	225-MAPBGA	13 mm	13 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MXLVM15R2	150 MHz	0 °C	70 °C	LCD	256-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	256-PBGA	14 mm	14 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MX1DVM15R2	150 MHz	-30 °C	70 °C	LCD Touch Panel	256-MAPBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core				ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MX1DVH20	200 MHz	-30 °C	70 °C	LCD Touch Panel	256-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	256-PBGA	14 mm	14 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MXLDVP20	200 MHz	-30 °C	70 °C	LCD	225-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	225-MAPBGA	13 mm	13 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MXLDVP20R2	200 MHz	-30 °C	70 °C	LCD	225-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	225-MAPBGA	13 mm	13 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MXLDVP15	150 MHz	-30 °C	70 °C	LCD	225-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	225-MAPBGA	13 mm	13 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
NXP USA Inc. MC9328MX21SVMR2	266 MHz	0 °C	70 °C	Keypad LCD	289-LFBGA	1-Wire I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	289-PBGA	17 mm	17 mm	ARM926EJ-S	3 V	1.8 V	No	USB 1.x (2)	SDRAM
NXP USA Inc. MC9328MXLVM20R2	200 MHz	0 °C	70 °C	LCD	256-LFBGA	I2C I2S MMC SD SPI SSI UART	Surface Mount	32 Bit	1 Core	256-PBGA	14 mm	14 mm	ARM920T	3 V	1.8 V	No	USB 1.x (1)	SDRAM
