NEVH22M160CD
ActiveNTE Electronics, Inc
CAP ALUM 22UF 160V RADIAL
NEVH22M160CD
ActiveNTE Electronics, Inc
CAP ALUM 22UF 160V RADIAL
Description
General part information
NEVH22M160CD
22 µF 160 V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | NEVH22M160CD |
|---|---|
| Applications | General Purpose |
| Capacitance | 22 µF |
| Height - Seated (Max) | 0.866 in |
| Lead Spacing | 0.197 in |
| Lifetime | 1000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Polarization | Polar |
| Size / Dimension Diameter | 0.394 in |
| Tolerance (Negative) | 10 % |
| Tolerance (Positive) | 75 % |
| Voltage - Rated | 160 V |
