1980721
ObsoletePhoenix Contact
TERM BLOCK HDR 4POS VERT 6.2MM
1980721
ObsoletePhoenix Contact
TERM BLOCK HDR 4POS VERT 6.2MM
Description
General part information
1980721
4 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.244" (6.20mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1980721 |
|---|---|
| Color | Gray |
| Current - IEC | 32 A |
| Current - UL | 20 A |
| Header Orientation | Vertical |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.988 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 4 |
| Pitch | 0.244 in |
| Positions Per Level | 4 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 800 V |
| Voltage - UL | 600 V |
