Specification	MLS771M100EA0D

Applications	General Purpose
Capacitance	770 µF
ESR (Equivalent Series Resistance)	238 mOhm
Height - Seated (Max)	12.7 mm
Lead Spacing	1 in
Lifetime	10000 Hrs
Mounting Type	Chassis Mount
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	Tabbed, FlatPack
Polarization	Polar
Ripple Current	6.6 A, 7.8 A
Size / Dimension Length	2 in
Size / Dimension Width	1.75 in
Tolerance	20 %
Voltage - Rated	100 VAC/DC
