806-108
ActiveWAGO Corporation
WIRE-TO-BOARD TERMINAL BLOCK, PLUGGABLE, 5 MM, 8 POSITIONS, 24 AWG, 16 AWG, 1.5 MM², PUSH IN
806-108
ActiveWAGO Corporation
WIRE-TO-BOARD TERMINAL BLOCK, PLUGGABLE, 5 MM, 8 POSITIONS, 24 AWG, 16 AWG, 1.5 MM², PUSH IN
Description
General part information
806-108
8 Position Wire to Board Terminal Block Vertical with Board 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 806-108 |
|---|---|
| Clamp Material | Steel |
| Clamp Plating | Nickel Plated |
| Color | Gray |
| Contact Material | Copper Alloy |
| Current | 10 A |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Mating Orientation | Vertical with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -60 °C |
| Pitch | 0.197 in |
| Plating | Tin Plated |
| Positions Per Level | 8 |
| Voltage | 300 V |
| Wire Gauge (AWG) (Max) | 24 AWG |
| Wire Gauge (AWG) (Min) | 16 AWG |
| Wire Termination | Leg Spring, Screwless, Push-In Spring |
