55107-01

Active

Cole Hersee

SWITCH TOGGLE SPDT 15A 24V

Search across all available documentation for this part.

Active

Cole Hersee

SWITCH TOGGLE SPDT 15A 24V

Technical Specifications

Parameters and characteristics for this part

Specification	55107-01

Actuator Length [x]	17.46 mm
Actuator Material	Brass, Nickel Plated
Actuator Type	Standard Round
Bushing Thread	15/32-32
Circuit	SPDT
Current Rating (Amps)	15 A
Illumination	Non-Illuminated
Panel Cutout Dimensions [diameter]	11.9 mm
Switch Function	On-On
Termination Style	Quick Connect - 0.250" (6.3mm)
Voltage Rating - DC	24 V

SWITCH TOGGLE SPDT 15A 24V

Part	Actuator Length [x]	Voltage Rating - DC	Illumination	Actuator Material	Termination Style	Circuit	Bushing Thread	Switch Function	Actuator Type	Current Rating (Amps)	Panel Cutout Dimensions [diameter]
Cole Hersee 55107-01	17.46 mm	24 V	Non-Illuminated	Brass, Nickel Plated	Quick Connect - 0.250" (6.3mm)	SPDT	15/32-32	On-On	Standard Round	15 A	11.9 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	80	$ 23.38

General part information

Toggle Switch SPDT Panel Mount
