G322209000
ActiveExcelitas Technologies
LENS ACHR VIS 40MM
G322209000
ActiveExcelitas Technologies
LENS ACHR VIS 40MM
Description
General part information
G322209000
LENS ACHR VIS 40MM
Technical Specifications
Parameters and characteristics for this part
| Specification | G322209000 |
|---|---|
| Focal Length | 40 mm |
| Mounting Type | Unmounted |
| Optic Center Thickness | 7 mm |
| Optic Diameter | 18 mm |
| Optic Edge Thickness | 4.5 mm |
| Type | Achromatic Lens |
| Wavelength (Max) | 700 nm |
| Wavelength (Min) | 450 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
