EVB222-15

Active

Allegro MicroSystems

EVAL BOARD FOR CT220

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsXtremeSense™ TMR technology

EVB222-15

Active

Allegro MicroSystems

EVAL BOARD FOR CT220

Deep-Dive with AI

DocumentsXtremeSense™ TMR technology

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	EVB222-15

Embedded	False
Interface	Analog
Sensing Range	15 mT
Sensitivity	30 mV/A
Sensor Type	Current Sensor
Supplied Contents	Board(s)
Voltage - Supply [Max]	5 V
Voltage - Supply [Min]	3 V

CT220 Series

Part	Supplied Contents	Interface	Sensing Range	Voltage - Supply [Min]	Voltage - Supply [Max]	Sensor Type	Sensitivity	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	For Measuring	Current - Supply (Max) [Max]	Number of Channels	Package / Case	Output	Linearity	Accuracy	Response Time	Frequency	Supplier Device Package	Mounting Type
Allegro MicroSystems CTD221-5.0	Board(s)	Analog	5 mT	2.7 V	5.5 V	Current Sensor
Allegro MicroSystems CT220FMV-HS5				2.7 V	5.5 V	Magnetoresistive	450 mV/mT	Bidirectional	125 °C	-40 °C	AC/DC	2.5 mA	1	SC-74A SOT-753	Current Ratiometric Voltage	0.15 %	0.5 %	20 µs	DC ~ 200kHz	SOT-23-5	Surface Mount
Allegro MicroSystems EVB222-1.5	Board(s)	Analog	1.5 mT	3 V	5 V	Current Sensor	300 fF/%RH
Allegro MicroSystems CT220RMV-IS5				2.7 V	5.5 V	Magnetoresistive	150 mV/A	Bidirectional	85 °C	-40 °C	AC/DC	2.5 mA	1	SC-74A SOT-753	Current Ratiometric Voltage	0.3 %	0.5 %	20 µs	DC ~ 200kHz	SOT-23-5	Surface Mount
Allegro MicroSystems CT220RMC-HS5				2.7 V	5.5 V	Magnetoresistive	150 mV/A	Bidirectional	125 °C	-40 °C	AC/DC	2.5 mA	1	SC-74A SOT-753	Current Ratiometric Voltage	0.3 %	0.5 %	20 µs	DC ~ 200kHz	SOT-23-5	Surface Mount
Allegro MicroSystems EVB222-15	Board(s)	Analog	15 mT	3 V	5 V	Current Sensor	30 mV/A
Allegro MicroSystems CT220FMC-IS5				2.7 V	5.5 V	Magnetoresistive	450 mV/mT	Bidirectional	85 °C	-40 °C	AC/DC	2.5 mA	1	SC-74A SOT-753	Current Ratiometric Voltage	0.15 %	0.5 %	20 µs	DC ~ 200kHz	SOT-23-5	Surface Mount
Allegro MicroSystems CT220FMC-HS5				2.7 V	5.5 V	Magnetoresistive	450 mV/mT	Bidirectional	125 °C	-40 °C	AC/DC	2.5 mA	1	SC-74A SOT-753	Current Ratiometric Voltage	0.15 %	0.5 %	20 µs	DC ~ 200kHz	SOT-23-5	Surface Mount
Allegro MicroSystems CT220BMV-IS5				2.7 V	5.5 V	Magnetoresistive	1500 mV/mT	Bidirectional	85 °C	-40 °C	AC/DC	2.5 mA	1	SC-74A SOT-753	Current Ratiometric Voltage	0.15 %	0.5 %	20 µs	DC ~ 200kHz	SOT-23-5	Surface Mount

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 95.22

Description

General part information

CT220 Series

CT220 XtremeSense™ Crocus Technology Current Sensor Sensor Evaluation Board

Documents

Technical documentation and resources

XtremeSense™ TMR technology

Datasheet
