HFWLF24-153T
ActiveAllied Components International
CMC 15MH 3.5A 2LN TH
HFWLF24-153T
ActiveAllied Components International
CMC 15MH 3.5A 2LN TH
Description
General part information
HFWLF24-153T
15 mH @ 100 kHz 2 Line Common Mode Choke Through Hole 3.5A DCR
Technical Specifications
Parameters and characteristics for this part
| Specification | HFWLF24-153T |
|---|---|
| Current Rating (Max) | 3.5 A |
| Height (Max) | 0.551 in |
| Inductance | 15 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 120 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | 4 PC Pin, Horizontal |
| Package Leads | 4 Leads |
| Package Name | Horizontal |
| Size / Dimension Length | 1.004 in |
| Size / Dimension Width | 0.906 in |
| Voltage Rating - AC | 250 V |
| Voltage Rating - DC | 250 VDC |
