Description
General part information
CTHFW2918F-3R3M
3.3 µH Shielded Wirewound Inductor 28 A 2.86mOhm Max 2-SMD, Gull Wing
Technical Specifications
Parameters and characteristics for this part
| Specification | CTHFW2918F-3R3M |
|---|---|
| Current - Saturation (Isat) | 92.5 A |
| Current Rating | 28 A |
| DC Resistance (DCR) (Max) | 2.86 mOhm |
| Height - Seated (Max) | 0.701 in |
| Inductance | 3.3 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Gull Wing, 2-SMD |
| Shielding | Shielded |
| Size / Dimension Length | 1.098 in |
| Size / Dimension Width | 1.098 in |
| Tolerance | 20 % |
| Type | Wirewound |
