Specification	3849

Bundle Center to Mounting Center	0.75 in
Color	Gray
Height	0.99 in
Length	1.38 in
Material	Nylon 6, 6, Polyamide (PA66)
Material Flammability Rating	UL94 V-2
Mounting Type	Arrowhead
Panel Hole Size	0.25 in
Panel Thickness (Max)	0.08 in
Panel Thickness (Min)	0.02 in
Type	Clip, C-Type
Type Attributes	Round, Locking
Width	0.67 in
