Description
General part information
C44APGP4680ZB0J
6.8 µF Film Capacitor 500V 1200V (1.2kV) Polypropylene (PP), Metallized Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | C44APGP4680ZB0J |
|---|---|
| Applications | General Purpose |
| Capacitance | 6.8 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 2 mOhm |
| Height - Seated (Max) | 4.055 in |
| Lead Spacing | 0.878 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 2.362 in |
| Termination | Threaded, Male |
| Tolerance | 5 % |
| Voltage Rating - AC | 500 V |
| Voltage Rating - DC | 1200 V |
