Description
General part information
SFPC160GM1AG2TO-C-8C-51P-STD
Solid State Drive (SSD) FLASH - NAND (TLC) 160GB NVMe M.2 Module 3.3V
Technical Specifications
Parameters and characteristics for this part
| Specification | SFPC160GM1AG2TO-C-8C-51P-STD |
|---|---|
| Form Factor | M.2 Module |
| Memory Size | 160 GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Size / Dimension Height | 2.23 mm |
| Size / Dimension Length | 80 mm |
| Size / Dimension Width | 22 mm |
| Speed - Read | 1.6 GB/s |
| Speed - Write | 1 GB/s |
| Type | NVMe |
| Voltage - Supply | 3.3 V |
