A-BAT-CH-CA-EG-ZTP3
ActiveAssmann WSW Components
BATTERY HOLDER COIN 24.5MM SMD
A-BAT-CH-CA-EG-ZTP3
ActiveAssmann WSW Components
BATTERY HOLDER COIN 24.5MM SMD
Description
General part information
A-BAT-CH-CA-EG-ZTP3
Battery Holder (Open) Coin, 24.5mm 1 Cell SMD (SMT) Tab
Technical Specifications
Parameters and characteristics for this part
| Specification | A-BAT-CH-CA-EG-ZTP3 |
|---|---|
| Battery Cell Size | Coin |
| Battery Cell Size Dimension | 24.5 mm |
| Battery Series (Cell Count) | 2430 |
| Battery Type | Coin Cell |
| Function | Holder |
| Height Above Board | 0.307 in |
| Mounting Type | Through Hole, PCB |
| Number of Cells | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Style | Holder (Open) |
| Termination Style | SMD (SMT) Tab |
