PCSV80-220M-RC
ActiveAllied Components International
FIXED IND 22UH 2.6A 80 MOHM SMD
PCSV80-220M-RC
ActiveAllied Components International
FIXED IND 22UH 2.6A 80 MOHM SMD
Description
General part information
PCSV80-220M-RC
22 µH Shielded Wirewound Inductor 2.6 A 80mOhm Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCSV80-220M-RC |
|---|---|
| Current - Saturation (Isat) | 2.8 A |
| Current Rating | 2.6 A |
| DC Resistance (DCR) | 80 mOhm |
| Height - Seated (Max) | 0.165 in |
| Inductance | 22 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.315 in |
| Size / Dimension Width | 0.315 in |
| Tolerance | 20 % |
| Type | Wirewound |
