RSMF3JB62K0
ActiveStackpole Electronics Inc
RES 62K OHM 5% 3W AXIAL
RSMF3JB62K0
ActiveStackpole Electronics Inc
RES 62K OHM 5% 3W AXIAL
Description
General part information
RSMF3JB62K0
62 kOhms ±5% 3W Through Hole Resistor Axial Flame Proof, Safety Metal Oxide Film
Technical Specifications
Parameters and characteristics for this part
| Specification | RSMF3JB62K0 |
|---|---|
| Composition | Metal Oxide Film |
| Features | Safety, Flame Proof |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 235 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 3 W |
| Resistance | 62 kOhm |
| Size / Dimension Diameter | 0.217 in |
| Size / Dimension Length | 0.591 in |
| Temperature Coefficient | 200 ppm/°C |
| Tolerance | 5 % |
