TAP650JR25E
250 mOhms ±5% 650W Thick Film Chassis Mount Resistor
Technical Specifications
Parameters and characteristics for this part
| Specification | TAP650JR25E |
|---|---|
| Coating | Epoxy Coated |
| Composition | Thick Film |
| Height - Seated (Max) | 0.532 in |
| Housing Type | Epoxy Coated |
| Lead Style | Wire Leads |
| Mounting Feature | Flanges, Screw Holes |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Box, Rectangular Case |
| Power (Watts) | 650 W |
| Resistance | 0.25 Ohms |
| Size / Dimension Length | 2.264 in |
| Size / Dimension Width | 2.028 in |
| Temperature Coefficient | 150 ppm/¯C |
| Tolerance | 5 % |
