PCHC128H-150M
ActiveAllied Components International
15UH +/-20% SHIELDED HI-CURRENT
PCHC128H-150M
ActiveAllied Components International
15UH +/-20% SHIELDED HI-CURRENT
Description
General part information
PCHC128H-150M
15 µH Shielded Inductor 31mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCHC128H-150M |
|---|---|
| Current - Saturation (Isat) | 9 A |
| DC Resistance (DCR) (Max) | 31 mOhm |
| Height - Seated (Max) | 0.315 in |
| Inductance | 15 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.492 in |
| Size / Dimension Width | 0.492 in |
| Tolerance | 20 % |
