TTM4005S-24VDC
ActiveAUTONICS
RELAY TIME DELAY 5SEC 3A 240V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TTM4005S-24VDC
ActiveAUTONICS
RELAY TIME DELAY 5SEC 3A 240V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TTM4005S-24VDC |
|---|---|
| Circuit | 4 Form C |
| Circuit | 4PDT |
| Contact Rating @ Voltage | 240 VAC, 3 A |
| Delay Time [Max] | 5 Sec |
| Delay Time [Min] | 0.1 Sec |
| Function | On-Delay |
| Mounting Type | Socketable |
| Termination Style | Plug In, 14 Pin |
| Timing Adjustment Method | Hand Dial |
| Voltage - Supply | 24 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 25.20 | |
Description
General part information
TTM4005 Series
On-Delay Time Delay Relay 4PDT (4 Form C) 0.1 Sec ~ 5 Sec Delay 3A @ 240VAC Socketable
