2810793
ObsoletePhoenix Contact
MCR 3-WAY ISOLATING AMPLIFIER
2810793
ObsoletePhoenix Contact
MCR 3-WAY ISOLATING AMPLIFIER
Description
General part information
2810793
MCR 3-WAY ISOLATING AMPLIFIER
Technical Specifications
Parameters and characteristics for this part
| Specification | 2810793 |
|---|---|
| Input Range Types | Voltage, Current |
| Input Type | Voltage |
| Input Voltage Range (Maximum) | 3 V |
| Input Voltage Range (Minimum) | -3 V |
| Isolation | 1500 V |
| Mounting Type | DIN Rail |
| Operating Temperature (Max) | 65 °C |
| Operating Temperature (Min) | -20 °C |
| Output Current Range (Max) | 20 mA |
| Output Current Range (Min) | 0 mA |
| Output Type | Current, Voltage |
| Output Voltage Range (Max) | 10 VDC |
| Output Voltage Range (Min) | 0 VDC |
| Termination Style | Screw Terminal |
| Type | Signal Conditioner |
