Description
General part information
L40S200D15CJ
Current Sensor 200A 1 Channel Hall Effect, Open Loop Bidirectional Module
Technical Specifications
Parameters and characteristics for this part
| Specification | L40S200D15CJ |
|---|---|
| Current - Sensing | 200 A |
| Current - Supply (Max) | 25 mA |
| For Measuring | AC, DC |
| Linearity Tolerance | 0.1 % |
| Maximum Frequency | 25 kHz |
| Minimum Frequency | DC |
| Mounting Type | Chassis Mount |
| Number of Channels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Output | Voltage, Ratiometric |
| Package / Case | Module |
| Polarization | Bidirectional |
| Response Time | 5 µs |
| Sensor Type | Hall Effect, Open Loop |
| Voltage - Supply (Maximum) | 15 V |
| Voltage - Supply (Minimum) | -12 V |
