RAD.1S.304.CLL
ActiveLEMO
CONN ADPT 4P-4P F/M-F/M PNL MNT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
RAD.1S.304.CLL
ActiveLEMO
CONN ADPT 4P-4P F/M-F/M PNL MNT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | RAD.1S.304.CLL | RAD.1S Series |
|---|---|---|
| Adapter Series | - | NIM-CAMAC CD/N 549 to NIM-CAMAC CD/N 549 |
| Adapter Type | - | Jack to Jack |
| Body Finish | - | Chrome |
| Body Material | - | Brass |
| Center Contact Plating | - | Gold |
| Center Gender | - | Female to Female |
| Connector Style | Standard | Standard |
| Conversion Type | - | Same Series |
| Convert From (Adapter End) | Female Sockets and Male Pins | Female Sockets and Male Pins, NIM-CAMAC CD/N 549 Jack, Female Socket, NIM-CAMAC CD/N 549 Triaxial Jack, Female Socket |
| Convert To (Adapter End) | Female Sockets, Male Pins | Female Sockets, Male Pins, NIM-CAMAC CD/N 549 Triaxial Jack, Female Socket |
| Current Rating (Amps) | 10 A | 7 - 15 A |
| Dielectric Material | - | Polytetrafluoroethylene (PTFE) |
| Fastening Type | Push-Pull | Push-Pull |
| Features | Mounting Hardware | Mounting Hardware |
| Housing Color | Silver | Silver |
| Housing Finish | Chrome | Chrome |
| Housing Material | Brass | Brass |
| Impedance | - | 50 Ohms |
| Includes | 1 Adapter, 1 Nut, 1 Washer | 1 Adapter, 1 Nut, 1 Washer, 1 Connector, 1 Lockwasher |
| Ingress Protection | IP50 | IP50 |
| Mating Cycles | - | 1000 - 5000 |
| Mounting Feature | Bulkhead - Rear Side Nut | Bulkhead - Rear Side Nut, Bulkhead |
| Number of Positions (Convert From) | 4 | 2 - 6 |
| Number of Positions (Convert To) | 4 | 2 - 6 |
| Operating Temperature [Max] | 250 °C | 250 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Orientation (Convert From) | Keyed | Keyed |
| Orientation (Convert To) | Keyed | Keyed |
| Shell Size - Insert (Convert From) | 304 | 302 - 306 |
| Shell Size - Insert (Convert To) | - | 306 |
| Shell Size - Insert (Convert To) [custom] | 304 | 302 - 304 |
| Shielding | Shielded | Shielded |
| Style | - | Straight |
RAD.1S Series
CONN ADPT 2P-2P F/M-F/M PNL MNT
| Part | Shielding | Orientation (Convert To) | Convert From (Adapter End) | Shell Size - Insert (Convert From) | Housing Finish | Connector Style | Features | Includes | Housing Material | Ingress Protection | Operating Temperature [Min] | Operating Temperature [Max] | Housing Color | Number of Positions (Convert From) | Fastening Type | Convert To (Adapter End) | Number of Positions (Convert To) | Current Rating (Amps) | Mounting Feature | Shell Size - Insert (Convert To) [custom] | Orientation (Convert From) | Conversion Type | Dielectric Material | Center Contact Plating | Adapter Series | Body Material | Center Gender | Style | Adapter Type | Mating Cycles | Body Finish | Impedance | Shell Size - Insert (Convert To) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO RAD.1S.302.CLL | Shielded | Keyed | Female Sockets and Male Pins | 302 | Chrome | Standard | Mounting Hardware | 1 Adapter, 1 Nut, 1 Washer | Brass | IP50 | -55 °C | 250 °C | Silver | 2 | Push-Pull | Female Sockets, Male Pins | 2 | 15 A | Bulkhead - Rear Side Nut | 302 | Keyed | ||||||||||||
LEMO RAD.1S.250.CTM | NIM-CAMAC CD/N 549 Jack, Female Socket | 1 Connector, 1 Lockwasher, 1 Nut | IP50 | -55 °C | 250 °C | Push-Pull | Bulkhead | Same Series | Polytetrafluoroethylene (PTFE) | Gold | NIM-CAMAC CD/N 549 to NIM-CAMAC CD/N 549 | Brass | Female to Female | Straight | Jack to Jack | 1000 | Chrome | 50 Ohms | |||||||||||||||
LEMO RAD.1S.650.CTM | NIM-CAMAC CD/N 549 Triaxial Jack, Female Socket | 1 Connector, 1 Lockwasher, 1 Nut | IP50 | -55 °C | 250 °C | Push-Pull | NIM-CAMAC CD/N 549 Triaxial Jack, Female Socket | Bulkhead | Same Series | Polytetrafluoroethylene (PTFE) | Gold | NIM-CAMAC CD/N 549 to NIM-CAMAC CD/N 549 | Brass | Female to Female | Straight | Jack to Jack | 5000 | Chrome | 50 Ohms | ||||||||||||||
LEMO RAD.1S.306.CLL | Shielded | Keyed | Female Sockets and Male Pins | 306 | Chrome | Standard | Mounting Hardware | 1 Adapter, 1 Nut, 1 Washer | Brass | IP50 | -55 °C | 250 °C | Silver | 6 | Push-Pull | Female Sockets, Male Pins | 6 | 7 A | Bulkhead - Rear Side Nut | Keyed | 306 | ||||||||||||
LEMO RAD.1S.304.CLL | Shielded | Keyed | Female Sockets and Male Pins | 304 | Chrome | Standard | Mounting Hardware | 1 Adapter, 1 Nut, 1 Washer | Brass | IP50 | -55 °C | 250 °C | Silver | 4 | Push-Pull | Female Sockets, Male Pins | 4 | 10 A | Bulkhead - Rear Side Nut | 304 | Keyed |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 65.94 | |
| 10 | $ 51.15 | |||
| 25 | $ 46.47 | |||
| 50 | $ 43.31 | |||
| 100 | $ 40.45 | |||
| 250 | $ 37.08 | |||
Description
General part information
RAD.1S Series
Circular Connector Standard 4/4 Female Sockets and Male Pins/Female Sockets and Male Pins Panel Mount
