0AKHBK350-BA
ActiveBel Fuse Inc.
FUSE 350A 1000V STUD MNT
0AKHBK350-BA
ActiveBel Fuse Inc.
FUSE 350A 1000V STUD MNT
Description
General part information
0AKHBK350-BA
350A 1 kVDC Fuse Square Bolt Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 0AKHBK350-BA |
|---|---|
| Applications | Electrical, Industrial |
| Breaking Capacity | 50 kA |
| Class | aR |
| Current Rating | 350 A |
| Fuse Type | Square |
| Mounting Type | Bolt Mount |
| Package / Case | Rectangular, Blade |
| Response Time | Fast Blow |
| Size / Dimension Height | 1.89 in |
| Size / Dimension Length | 2.827 in |
| Size / Dimension Width | 1.85 in |
| Voltage Rating - DC | 1 kV |
