Specification	4905-1-3(5)

Adhesive	Acrylic
Backing	Polyester Film
Carrier	Polyester Film
Color	Clear
Length	3 "
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature (Maximum)	100 °F
Storage/Refrigeration Temperature (Minimum)	40 °F
Tape Type	Double Sided, Double Coated
Temperature Range (Single)	200 °F
Thickness	0.02 in
Usage	General Purpose
Width	1 in

4905 Series

...

Part	Storage/Refrigeration Temperature (Minimum)	Storage/Refrigeration Temperature (Maximum)	Shelf Life	Shelf Life Start	Length	Color	Thickness	Thickness - Backing, Carrier	Tape Type	Carrier	Backing	Thickness - Adhesive	Adhesive	Width	Temperature Range (Max)	Length (yd)	Length (ft)	Usage	Temperature Range (Single)
3M (TC) 3M 4905 8" X 10"-10	40 °F	100 °F	24 Months	Date of Shipment	10 in	Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	8 in	200 °F
3M (TC) 3M 4905 8" X 9"-10	40 °F	100 °F	24 Months	Date of Shipment	228.6 mm	Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	8 in	200 °F
3M (TC) 4905-1.875-5	40 °F	100 °F	24 Months	Date of Shipment		Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	1.88 in	200 °F	5 yd	15 ft
3M (TC) 3M 4905 9" X 9"-10	40 °F	100 °F	24 Months	Date of Shipment	228.6 mm	Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	9 in	200 °F
3M (TC) 4905-6-1	40 °F	100 °F	24 Months	Date of Shipment		Clear	0.02 in		Double Coated Double Sided	Polyethylene Film	Polyethylene Film		Acrylic	6 in	199 °F	1 yd	3 ft	General Purpose
3M (TC) 3M 4905 6" X 8"-10	40 °F	100 °F	24 Months	Date of Shipment	8 in	Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	6 in	200 °F
3M (TC) 4905CIR-0.563(2000)	40 °F	100 °F	24 Months	Date of Shipment		Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	0.56 in	200 °F
3M (TC) 4905-4-5	40 °F	100 °F	24 Months	Date of Shipment		Clear	0.02 in		Double Coated Double Sided	Polyethylene Film	Polyethylene Film		Acrylic	4 in		5 yd	15 ft	General Purpose	200 °F
3M (TC) 4905-5-6(25)	40 °F	100 °F	24 Months	Date of Shipment	0.5 ft	Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	5 in	200 °F
3M (TC) 3M 4905 5" X 8"-25	40 °F	100 °F	24 Months	Date of Shipment	8 in	Clear	0.02 in	0.005 in	Double Coated Double Sided	Polyethylene Film	Polyethylene Film	0.015 in	Acrylic	5 in	200 °F
