BXEM-35E0000-0-000

Active

BRIDGELUX

LED 3030 WARM WHT 3500K SMD

Search across all available documentation for this part.

Active

BRIDGELUX

LED 3030 WARM WHT 3500K SMD

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	BXEM-35E0000-0-000	BXEM-35 Series

CCT (K)	3500 K	3500 K
Color	White, Warm	White, Warm
CRI (Color Rendering Index)	80	80
Current - Max [Max]	240 mA	240 - 400 mA
Current - Test	150 mA	150 - 300 mA
Flux @ 85°C, Current - Test	105 lm	105 lm
Height - Seated (Max) [Max]	0.024 in	0.024 in
Height - Seated (Max) [Max]	0.62 mm	0.62 mm
Lumens/Watt @ Current - Test	117 lm/W	117 lm/W
Mounting Type	Surface Mount	Surface Mount
Package / Case	1212	1212
Package / Case	3030 Metric	3030 Metric
Size / Dimension [x]	0.118 in	0.118 in
Size / Dimension [x]	3 mm	3 mm
Size / Dimension [y]	3 mm	3 mm
Size / Dimension [y]	0.118 in	0.118 in
Supplier Device Package	3030	3030
Thermal Resistance of Package [custom]	12 °C/W	12 °C/W
Viewing Angle	120 °	120 °
Voltage - Forward (Vf) (Typ)	6 V	3 - 6 V

LED GEN2 WARM WHT 3500K 3030

Part	Thermal Resistance of Package [custom]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	CCT (K)	Lumens/Watt @ Current - Test	Mounting Type	Supplier Device Package	CRI (Color Rendering Index)	Voltage - Forward (Vf) (Typ)	Package / Case	Package / Case	Current - Test	Current - Max [Max]	Viewing Angle	Color	Flux @ 85°C, Current - Test	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
BRIDGELUX BXEM-35E-21H-3A-00-0-0	12 °C/W	0.118 in	3 mm	3 mm	0.118 in	3500 K	117 lm/W	Surface Mount	3030	80	3 V	1212	3030 Metric	300 mA	400 mA	120 °	Warm, White	105 lm	0.024 in	0.62 mm
BRIDGELUX BXEM-35E0000-0-000	12 °C/W	0.118 in	3 mm	3 mm	0.118 in	3500 K	117 lm/W	Surface Mount	3030	80	6 V	1212	3030 Metric	150 mA	240 mA	120 °	Warm, White	105 lm	0.024 in	0.62 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Lighting 3030 White, Warm 3500K 6V 150mA 120° 1212 (3030 Metric)
