12.85615
ActiveGeyer Electronic America, Inc.
CRYSTAL, 48MHZ, 9PF, SMD
12.85615
ActiveGeyer Electronic America, Inc.
CRYSTAL, 48MHZ, 9PF, SMD
Description
General part information
12.85615
48 MHz ±10ppm Crystal 9pF 50 Ohms 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | 12.85615 |
|---|---|
| ESR (Equivalent Series Resistance) | 50 Ohm |
| Frequency | 48 MHz |
| Frequency Stability | 10 ppm, 8 ppm |
| Frequency Tolerance | 8 ppm, 10 ppm |
| Height - Seated (Max) | 0.02 in, 0.018 in |
| Load Capacitance | 9 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C, -40 °C |
| Package / Case | 4-SMD, No Lead |
| Package Length | 2 mm |
| Package Name | 4-SMD |
| Package Width | 1.6 mm |
| Size / Dimension Length | 0.079 in |
| Size / Dimension Width | 0.063 in |
