9451 006U1000

Active

Belden Inc.

CABLE 2CON 22AWG BLUE SHLD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

9451 006U1000

Active

Belden Inc.

CABLE 2CON 22AWG BLUE SHLD

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9451 006U1000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.135 in
Jacket (Insulation) Diameter [diameter]	3.43 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.02 in
Jacket (Insulation) Thickness	0.508 mm
Jacket Color	Blue
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Ratings	UL Style CMR
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Wire Gauge	22 AWG

9451 Series

Part	Number of Conductors	Jacket (Insulation) Material	Jacket Color	Shield Coverage	Conductor Strand [custom]	Conductor Strand [custom]	Usage	Wire Gauge	Shield Type	Conductor Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Shield Material	Voltage	Ratings	Features	Conductor Insulation	Length	Length
Belden Inc. 9451 0025000	2	Poly-Vinyl Chloride (PVC) Riser	Red	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)
Belden Inc. 9451 003U1000	2	Poly-Vinyl Chloride (PVC) Riser	Orange	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)	1000 ft	304.8 m
Belden Inc. 9451 N3U5000	2	Poly-Vinyl Chloride (PVC) Riser	Green	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)
Belden Inc. 9451 008U1000	2	Poly-Vinyl Chloride (PVC) Riser	Gray	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)	1000 ft	304.8 m
Belden Inc. 9451 0085000	2	Poly-Vinyl Chloride (PVC) Riser	Gray	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)
Belden Inc. 9451 010N1000	2	Poly-Vinyl Chloride (PVC) Riser	Black	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)	1000 ft	304.8 m
Belden Inc. 9451 0101000	2	Poly-Vinyl Chloride (PVC) Riser	Black	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)	1000 ft	304.8 m
Belden Inc. 9451 006U1000	2	Poly-Vinyl Chloride (PVC)	Blue	100 %	7	30 AWG		22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum		UL Style CMR		Polypropylene (PP)	1000 ft	304.8 m
Belden Inc. 9451 001U1000	2	Poly-Vinyl Chloride (PVC) Riser	Brown	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)	1000 ft	304.8 m
Belden Inc. 9451 007U1000	2	Poly-Vinyl Chloride (PVC) Riser	Violet	100 %	7	30 AWG	Audio	22 AWG	Foil	Copper Tinned	0.02 in	0.508 mm	0.135 in	3.43 mm	Multi-Conductor	Aluminum Polyester	300 V	UL Style CMR	Drain Wire	Polypropylene (PP)	1000 ft	304.8 m

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1000	$ 0.51

Description

General part information

9451 Series

2 (1 Pair Twisted) Conductor Multi-Conductor Cable Blue 22 AWG Foil 1000.0' (304.8m)
