SM91R
ActiveBANNER ENGINEERING
VALU-BEAM: RECEIVERRANGE: 60
SM91R
ActiveBANNER ENGINEERING
VALU-BEAM: RECEIVERRANGE: 60
Description
General part information
SM91R
Through-Beam Optical Sensor 196.85' (60m) NPN/PNP - Dark-ON/Light-ON - Selectable
Technical Specifications
Parameters and characteristics for this part
| Specification | SM91R |
|---|---|
| Adjustment Type | Adjustable, Potentiometer |
| Cable Length | 78.74 in |
| Connection Method | Cable |
| Ingress Protection | 4X, 12, 6, 13 IEC IP66, 4, NEMA 1, 6P, 3S, 3, 2, IEC, 13, IP66 |
| Light Source | Infrared |
| Light Source Wavelength (Infrared) | 880 nm |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Output Configuration | Light-ON - Selectable, Dark-ON, PNP, Selectable, Light-ON, PNP - Dark-ON, NPN |
| Response Time | 4 ms |
| Sensing Distance | 2362.2 " |
| Sensing Method | Through-Beam |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
