Description
General part information
W7FT1060
Enclosed AC DC Converters 1 Output 7V 90 ~ 132 VAC, 200 ~ 375 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | W7FT1060 |
|---|---|
| Applications | Industrial, ITE (Commercial) |
| Approval Agency | cURus, CE, cULus |
| Current - Output 1 | 10.6 A |
| Efficiency | 71 % |
| Features | DC Input Capable, Remote Sense |
| Minimum Load Required | No |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 71 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 74 W |
| Size / Dimension Height | 1.68 in |
| Size / Dimension Length | 6.59 in |
| Size / Dimension Width | 3.45 in |
| Standard Number | 60950-1, UL 508 |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 132 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Input (DC) Maximum | 375 VDC |
| Voltage - Input (DC) Minimum | 200 V |
| Voltage - Isolation | 4242 V |
| Voltage - Output 1 | 7 V |
