| 1st Connector | - | SMA Plug, 2.92mm Plug |
| 1st Connector Mounting Type | - | Free Hanging (In-Line) |
| 1st Contact Gender | - | Male |
| 2nd Connector | - | SMA Plug, N-Type Plug |
| 2nd Connector | - | 2.92 mm |
| 2nd Connector Mounting Type | - | Free Hanging (In-Line) |
| 2nd Contact Gender | - | Male |
| Adapter Series | SMA to SMA | SMA to SMA, N to N, BNC to BNC, BNC to N, SMA to RP-SMA, SMA to 3.5mm |
| Adapter Series | - | 2.4 - 3.5 mm |
| Adapter Series | - | 1.85 - 3.5 mm |
| Adapter Type | Jack to Jack | Plug to Jack, Jack to Jack, Plug to Plug |
| Attenuation Value | - | 0 - 15 dB |
| Attenuation Value | - | 4 - 20 dB |
| Body Material | Stainless Steel | Stainless Steel, Brass |
| Center Gender | Female to Female | Female to Female, Male to Male |
| Color | - | Blue |
| Connector Style | - | SMA, N Type, BNC |
| Connector Style | - | 2.92 mm |
| Connector Type | - | Female Socket, Jack, Male Pin, Plug |
| Conversion Type | Same Series | Same Series, Between Series |
| Convert From (Adapter End) | Female Socket, SMA Jack | SMA Plug, Male Pin, Female Socket, SMA Jack, OS-2.9, Jack, Female Socket, N Jack, 3.5mm Jack, Female Socket, 3.5mm Plug, Male Pin, N Plug, Male Pin, BNC Plug, Male Pin, 1.85mm Jack, Female Socket, RP-SMA Plug, Plug, Male Pin |
| Convert From (Adapter End) | - | 1.85 - 2.92 mm |
| Convert To (Adapter End) | SMA Jack, Female Socket | SMA Jack, Female Socket, N Jack, OS-2.9 Jack, Female Socket, 3.5mm Jack, BNC Jack, SMA Plug, Male Pin, N Plug, 2.92mm (OS-2.9) Plug, Male Pin, 2.4mm (APC-2.4, OS-50) Plug, Male Pin |
| Convert To (Adapter End) | - | 2.4 - 2.92 mm |
| Fastening Type | - | Bayonet Lock, Threaded |
| Features | - | Chain |
| Frequency - Max [Max] | 18 GHz | 2 - 6000 GHz |
| Frequency Range | - | 8 GHz |
| Frequency Range | - | 0 Hz |
| Impedance | 50 Ohms | 50 Ohms |
| Insertion Loss | - | 0.03 - 0.5 dB |
| Length | - | 91.44 - 1200 cm |
| Length | - | 24 - 48 in |
| Length | - | 4 ft |
| Mating Cycles | - | 500 |
| Mounting Feature | Bulkhead | Flange, Bulkhead |
| Mounting Type | - | Free Hanging, Cap, Free Hanging (In-Line), Right Angle |
| Operating Temperature [Max] | 100 °C | 28 - 125 °C |
| Operating Temperature [Min] | -55 °C | -65 - 18 °C |
| Overall Impedance | - | 50 Ohms |
| Package / Case | - | 4-SMD, No Lead |
| Power (Watts) | - | 0.5 W |
| Style | Straight | Straight, Right Angle, SMA to SMA, SMA to N-Type |
| Style | - | 2.92 mm |
| Style | - | 2.92 mm |
