KLKE-30
ActiveEaton - Electronics Division
FUSE EV 30A 600VAC/DC NO TERM
KLKE-30
ActiveEaton - Electronics Division
FUSE EV 30A 600VAC/DC NO TERM
Description
General part information
KLKE-30
30 A 600 V AC 600 V DC Fuse Cartridge, Ceramic Requires Holder 5AG, 10mm x 38.1mm
Technical Specifications
Parameters and characteristics for this part
| Specification | KLKE-30 |
|---|---|
| Approval Agency | cURus |
| Breaking Capacity | 50 kA |
| Current Rating | 30 A |
| DC Cold Resistance | 3.4 mOhm |
| Fuse Type | Cartridge, Ceramic |
| Mounting Type | Requires Holder |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 5AG, 10mm x 38.1mm |
| Package Diameter | 10 mm, 38.1 mm |
| Package Length | 10 mm |
| Package Name | 5AG |
| Package Width | 38.1 mm |
| Size / Dimension Diameter | 0.406 in |
| Size / Dimension Length | 1.496 in |
| Voltage Rating - AC | 600 VAC |
| Voltage Rating - DC | 600 V |
