NDD56PT6-2AET

Active

Insignis Technology Corporation

IC DRAM 512MBIT SSTL 66TSOPII

Search across all available documentation for this part.

Active

Insignis Technology Corporation

IC DRAM 512MBIT SSTL 66TSOPII

Technical Specifications

Parameters and characteristics commom to parts in this series

IC DRAM 512MBIT SSTL 66TSOPII

Part	Clock Frequency	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Format	Memory Interface	Memory Organization	Mounting Type	Supplier Device Package	Package / Case [custom]	Package / Case	Package / Case [custom]	Memory Type	Operating Temperature [Max]	Operating Temperature [Min]	Memory Size
Insignis Technology Corporation NDD56PT6-2AET	200 MHz	2.7 V	2.3 V	DRAM	SSTL_2	32M x 16	Surface Mount	66-TSOP II	0.4 in	66-TSSOP	0.4 in	Volatile	70 °C	0 °C	64 MB
Insignis Technology Corporation NDD56PT6-2AET TR	200 MHz	2.7 V	2.3 V	DRAM	SSTL_2	32M x 16	Surface Mount	66-TSOP II	0.4 in	66-TSSOP	0.4 in	Volatile	70 °C	0 °C	64 MB

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

SDRAM - DDR Memory IC 512Mbit SSTL_2 200 MHz 66-TSOP II
