AM2S-2409SZ
Activeaimtec
DC DC CONVERTER 9V 2W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM2S-2409SZ
Activeaimtec
DC DC CONVERTER 9V 2W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM2S-2409SZ |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) [Max] | 222 mA |
| Efficiency | 85 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SIP Module |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 0.46 in |
| Size / Dimension [x] | 11.7 mm |
| Size / Dimension [y] | 0.3 " |
| Size / Dimension [y] | 7.5 mm |
| Size / Dimension [z] | 10.2 mm |
| Size / Dimension [z] | 0.4 " |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 26.4 V |
| Voltage - Input (Min) [Min] | 21.6 V |
| Voltage - Isolation | 1000 V |
| Voltage - Output 1 | 9 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 8.42 | |
| 5 | $ 8.30 | |||
| 15 | $ 8.18 | |||
| 25 | $ 7.93 | |||
| 40 | $ 7.69 | |||
| 80 | $ 7.45 | |||
| 160 | $ 7.21 | |||
Description
General part information
AM2S-2409SZ
Isolated Module DC DC Converter 1 Output 9V 222mA 21.6V - 26.4V Input
