FBH321611T-501Y-S-H
ActiveCal-Chip Electronics, Inc.
FB HI 1206 500 OHM 3A .04DC
FBH321611T-501Y-S-H
ActiveCal-Chip Electronics, Inc.
FB HI 1206 500 OHM 3A .04DC
Description
General part information
FBH321611T-501Y-S-H
500 Ohms @ 100 MHz 1 Power Line Ferrite Bead 1206 (3216 Metric) 3A 40mOhm
Technical Specifications
Parameters and characteristics for this part
| Specification | FBH321611T-501Y-S-H |
|---|---|
| Current Rating (Max) | 3 A |
| DC Resistance (DCR) (Max) | 40 mOhm |
| Filter Type | Power Line |
| Height (Max) | 0.051 in |
| Impedance | 500 Ohms |
| Mounting Type | Surface Mount |
| Number of Lines | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension Length | 0.126 in |
| Size / Dimension Width | 0.063 in |
