Description
General part information
173109 Series
FCT Standard-Density D-Sub Connector, Male, Straight, PCB Through Hole, 10.30mm Tail Length, Gold Plating, 200 Mating Cycles, 6.30mm #4-40 Front Spacer, 6.50mm M3 Rear Spacer, 15 Circuits, White Insulator
Technical Specifications
Parameters and characteristics for this part
| Specification | 1731090574 |
|---|---|
| Color | Black |
| Connector Layout | DE, E |
| Connector Style | D-Sub |
| Connector Type | Receptacle for Female Contacts |
| Contact Type | Signal |
| Dielectric Material | Glass Filled, Polyamide (PA), Nylon |
| Finish | Tin Plated |
| Flange Feature | Cable Side (4-40) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Operating Temperature (Max) | 115 °C |
| Operating Temperature (Min) | -55 °C |
| Shell Material | Steel |
| Shell Size | 1 |
