A10 Series

Part	Diameter - Outside	Wire Diameter	Free Length	Rate (lbs/in)	Type	Diameter - Inside	Material	Finish	End Style	Load
Century Spring Corp A10-70CS	0.375 in	0.055 in	1.09 in	50 lbs/in	Compression	0.265 in	Spring Steel	Zinc	Closed Ground
Century Spring Corp A10-9CS	0.125 in	0.025 in	0.25 in	187 lbs/in	Compression	0.075 in	Music Wire	Black Oxide	Closed
Century Spring Corp A10-37CS	0.109 in	0.013 in	0.84 in	2.3 lbs/in	Compression	0.083 in	Stainless Steel	None	Closed
Century Spring Corp A10-48CS	0.219 in	0.019 in	1.28 in	1 lbs/in	Compression	0.181 in	Stainless Steel	None	Closed
Century Spring Corp A10-62CS	0.734 in	0.04 in	0.75 in	3.3 lbs/in	Compression	0.654 in	Stainless Steel	None	Closed Ground
Century Spring Corp A10-67CS	0.703 in	0.036 in	1.5 in	1.8 lbs/in	Compression	0.631 in	Stainless Steel	None	Closed
Century Spring Corp A10-1CS	0.36 in	0.024 in		0.96 lbs/in			Music Wire	None		2 lbs
Century Spring Corp A10-50CS	0.484 in	0.03 in	0.31 in	12 lbs/in	Compression	0.424 in	Music Wire	Gold Iridite	Closed Ground
Century Spring Corp A10-53CS	0.468 in	0.016 in	0.34 in	0.45 lbs/in	Compression	0.436 in	Stainless Steel	None	Closed
Century Spring Corp A10-8CS	0.234 in	0.019 in	0.53 in	3.4 lbs/in	Compression	0.196 in	Music Wire	None	Closed
