339B-359-R-2-X

Unknown

MUELLER ELECTRIC

RELAY TIME DELAY 3SEC 10A 250V

Search across all available documentation for this part.

Unknown

MUELLER ELECTRIC

RELAY TIME DELAY 3SEC 10A 250V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY TIME DELAY 3SEC 10A 250V

Part	Voltage - Supply	Delay Time [Max]	Delay Time [Min]	Relay Type	Mounting Type	Circuit	Termination Style	Timing Initiate Method	Contact Rating @ Voltage	Timing Adjustment Method
MUELLER ELECTRIC 339B-359-R-2-X	240 VAC	3 Sec	0.3 Sec	Mechanical Relay	Socketable	DPDT (2 Form C)	Plug In, 8 Pin (Octal)	Input Voltage	10 A, 30 VDC, 250 VAC	Hand Dial
MUELLER ELECTRIC 339B-359-Q-2-X	120 VAC	3 Sec	0.3 Sec	Mechanical Relay	Socketable	DPDT (2 Form C)	Plug In, 8 Pin (Octal)	Input Voltage	10 A, 30 VDC, 250 VAC	Hand Dial

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 107.50

General part information

Interval, On-Delay Time Delay Relay DPDT (2 Form C) 0.3 Sec ~ 3 Sec Delay 10A @ 250VAC/30VDC Socketable
