SG468020
ActiveCelduc Inc.
SSR RELAY SPST-NO 70A 200-460V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SG468020
ActiveCelduc Inc.
SSR RELAY SPST-NO 70A 200-460V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SG468020 |
|---|---|
| Load Current | 70 A |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | AC |
| Package / Case | Module |
| Voltage - Input [Max] | 10 V |
| Voltage - Input [Min] | 0 V |
| Voltage - Load [Max] | 460 V |
| Voltage - Load [Min] | 200 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 16 | $ 590.89 | |
Description
General part information
SG468020
Solid State SPST-NO (1 Form A) Module
Documents
Technical documentation and resources
