1332124
ActivePhoenix Contact
CONN MALE HDR 6.35MM 20POS SMD
1332124
ActivePhoenix Contact
CONN MALE HDR 6.35MM 20POS SMD
Description
General part information
1332124
20 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Technical Specifications
Parameters and characteristics for this part
| Specification | 1332124 |
|---|---|
| Connector Type | Outer Shroud Contacts, Header |
| Contact Finish | Gold |
| Features | Solder Retention |
| Height Above Board | 0.315 in |
| Mated Stacking Height Options | 9mm, 15mm |
| Mounting Type | Surface Mount |
| Number of Positions | 20 |
| Number of Rows | 2 |
| Pitch | 0.025 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
