RCT-1800-250
ActiveAim Dynamics
CURRENT SEN ROGOWSKI COIL 250A
RCT-1800-250
ActiveAim Dynamics
CURRENT SEN ROGOWSKI COIL 250A
Description
General part information
RCT-1800-250
Current Sensor 250A 1 Channel Current Sensor Module
Technical Specifications
Parameters and characteristics for this part
| Specification | RCT-1800-250 |
|---|---|
| Accuracy | 1 % |
| Current - Sensing | 250 A |
| For Measuring | AC |
| Mounting Type | Chassis Mount |
| Number of Channels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -20 °C |
| Output | Voltage, Ratiometric |
| Package / Case | Module |
| Sensor Type | Current Sensor |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 12 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
