CI0102M1VR0-NH

Active

Cvilux USA

2 POS 2.00MM(.079) SINGLE ROW SM

Search across all available documentation for this part.

Active

Cvilux USA

2 POS 2.00MM(.079) SINGLE ROW SM

Technical Specifications

Parameters and characteristics for this part

Specification	CI0102M1VR0-NH

Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	120 µin
Contact Finish Thickness - Mating	3.05 Ám
Contact Finish Thickness - Post	120 Áin
Contact Finish Thickness - Post	3.05 Ám
Contact Length - Mating	3.61 mm
Contact Length - Mating	0.142 in
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	2 A
Fastening Type	Detent Lock
Features	Pick and Place, Solder Retention
Insulation Color	Natural
Insulation Material	Polyamide (PA6T), Halogen Free, Nylon 6T
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	2
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-25 °C
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	250 VAC

2 POS 2.00MM(.079) SINGLE ROW SM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Features	Pitch - Mating [x]	Pitch - Mating [x]	Number of Positions Loaded	Termination	Fastening Type	Contact Finish - Post	Contact Material	Insulation Color	Shrouding	Current Rating (Amps)	Material Flammability Rating	Mounting Type	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Material	Contact Length - Mating	Contact Length - Mating	Number of Positions	Number of Rows	Contact Type	Contact Shape	Voltage Rating	Style	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating
Cvilux USA CI0102M1VR0-NH	120 Áin	3.05 Ám	Pick and Place, Solder Retention	0.079 in	2 mm	All	Solder	Detent Lock	Tin	Brass	Natural	Shrouded - 4 Wall	2 A	UL94 V-0	Surface Mount	Header	-25 °C	105 ░C	Halogen Free, Nylon 6T, Polyamide (PA6T)	3.61 mm	0.142 in	2	1	Male Pin	Square	250 VAC	Board to Cable/Wire	120 µin	3.05 Ám

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Header Surface Mount 2 position 0.079" (2.00mm)
