IS65WV1288BLL-55HLA1

Active

ISSI, Integrated Silicon Solution Inc

IC SRAM 1MBIT PARALLEL 32STSOP I

Deep-Dive with AI

Search across all available documentation for this part.

IS65WV1288BLL-55HLA1

Active

ISSI, Integrated Silicon Solution Inc

IC SRAM 1MBIT PARALLEL 32STSOP I

Deep-Dive with AI

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	468	$ 3.28

Description

General part information

IS65WV1288 Series

SRAM - Asynchronous Memory IC 1Mbit Parallel 55 ns 32-sTSOP I

Documents

Technical documentation and resources

No documents available

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	IS65WV1288BLL-55HLA1	IS65WV1288 Series

Access Time	55 ns	45 - 55 ns
Grade	-	Automotive
Memory Format	SRAM	SRAM
Memory Interface	Parallel	Parallel
Memory Organization	128K x 8	128K x 8
Memory Size	1 Mbit	1 Mbit
Memory Type	Volatile	Volatile
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	85 °C	85 - 125 °C
Operating Temperature [Min]	-40 °C	-40 - 0 °C
Package / Case	-	0.724 in
Package / Case	-	18.4 mm
Package / Case	-	32-TFSOP
Package / Case [custom]	32-TFSOP	32-TFSOP
Package / Case [x]	0.465 "	0.465 "
Package / Case [x]	11.8 mm	11.8 mm
Qualification	-	AEC-Q100
Supplier Device Package	32-sTSOP I	32-TSOP I, 32-sTSOP I
Technology	SRAM - Asynchronous	SRAM - Asynchronous, SRAM - Synchronous
Voltage - Supply [Max]	3.6 V	3.6 V
Voltage - Supply [Min]	2.5 V	2.2 - 2.5 V
Write Cycle Time - Word, Page [custom]	55 ns	45 - 55 ns
Write Cycle Time - Word, Page [custom]	55 ns	45 - 55 ns

IS65WV1288 Series

IC SRAM 1MBIT PARALLEL 32TSOP I

Part	Access Time	Package / Case	Package / Case	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Size	Memory Type	Operating Temperature [Min]	Operating Temperature [Max]	Memory Organization	Write Cycle Time - Word, Page [custom]	Write Cycle Time - Word, Page [custom]	Supplier Device Package	Memory Format	Memory Interface	Technology	Mounting Type	Grade	Qualification	Package / Case [x]	Package / Case [custom]	Package / Case [x]
ISSI, Integrated Silicon Solution Inc IS65WV1288DBLL-45TLA3	45 ns	0.724 in	18.4 mm	32-TFSOP	3.6 V	2.5 V	1 Mbit	Volatile	-40 °C	125 °C	128K x 8	45 ns	45 ns	32-TSOP I	SRAM	Parallel	SRAM - Asynchronous	Surface Mount
ISSI, Integrated Silicon Solution Inc IS65WV1288DBLL-45TLA3-TR	45 ns	0.724 in	18.4 mm	32-TFSOP	3.6 V	2.5 V	1 Mbit	Volatile	-40 °C	125 °C	128K x 8	45 ns	45 ns	32-TSOP I	SRAM	Parallel	SRAM - Asynchronous	Surface Mount
ISSI, Integrated Silicon Solution Inc IS65WV1288FBLL-55CTLA3-TR	55 ns	0.724 in	18.4 mm	32-TFSOP	3.6 V	2.2 V	1 Mbit	Volatile	-40 °C	125 °C	128K x 8	55 ns	55 ns	32-TSOP I	SRAM	Parallel	SRAM - Synchronous	Surface Mount	Automotive	AEC-Q100
ISSI, Integrated Silicon Solution Inc IS65WV1288BLL-55HLA1-TR	55 ns				3.6 V	2.5 V	1 Mbit	Volatile	-40 °C	85 °C	128K x 8	55 ns	55 ns	32-sTSOP I	SRAM	Parallel	SRAM - Asynchronous	Surface Mount			0.465 "	32-TFSOP	11.8 mm
ISSI, Integrated Silicon Solution Inc IS65WV1288BLL-55HLA1	55 ns				3.6 V	2.5 V	1 Mbit	Volatile	-40 °C	85 °C	128K x 8	55 ns	55 ns	32-sTSOP I	SRAM	Parallel	SRAM - Asynchronous	Surface Mount			0.465 "	32-TFSOP	11.8 mm
ISSI, Integrated Silicon Solution Inc IS65WV1288FBLL-55CTLA3	55 ns	0.724 in	18.4 mm	32-TFSOP	3.6 V	2.2 V	1 Mbit	Volatile	-40 °C	125 °C	128K x 8	55 ns	55 ns	32-TSOP I	SRAM	Parallel	SRAM - Synchronous	Surface Mount	Automotive	AEC-Q100
ISSI, Integrated Silicon Solution Inc IS65WV1288DBLL-45HLA3	45 ns				3.6 V	2.3 V	1 Mbit	Volatile	0 °C	125 °C	128K x 8	45 ns	45 ns	32-sTSOP I	SRAM	Parallel	SRAM - Asynchronous	Surface Mount			0.465 "	32-TFSOP	11.8 mm
