31041111
ObsoleteMETZ CONNECT USA Inc.
PIN HEADER, BACKWALL, VERTICAL,
31041111
ObsoleteMETZ CONNECT USA Inc.
PIN HEADER, BACKWALL, VERTICAL,
Description
General part information
31041111
11 Position Terminal Block Header, Male Pins, Shrouded (3 Side) 0.197" (5.00mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 31041111 |
|---|---|
| Color | Black |
| Contact Material | Copper Zinc |
| Contact Mating Finish | Silver |
| Contact Tail Length | 0.132 in |
| Current - UL | 15 A |
| Header Orientation | Vertical |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Insulation Height | 0.38 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 11 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.197 in |
| Positions Per Level | 11 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (3 Side), Header |
| Voltage - UL | 300 V |
