LGJ12565TS-331MR87-H
ObsoleteTDK Corporation
FIXED IND 330UH 950MA 494MOHM SM
LGJ12565TS-331MR87-H
ObsoleteTDK Corporation
FIXED IND 330UH 950MA 494MOHM SM
Description
General part information
LGJ12565TS-331MR87-H
330 µH Shielded Drum Core, Wirewound Inductor 950 mA 494mOhm Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | LGJ12565TS-331MR87-H |
|---|---|
| Current - Saturation (Isat) | 0.87 mA |
| Current Rating | 950 mA |
| DC Resistance (DCR) | 494 mOhm |
| Height - Seated (Max) | 0.256 in |
| Inductance | 330 µH |
| Inductance Frequency - Test | 1 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension Length | 0.492 in |
| Size / Dimension Width | 0.492 in |
| Tolerance | 20 % |
| Type | Drum Core, Wirewound |
